Lianxin is a professional manufacturer of high-quality PVC Barbed Wire, designed for effective security fencing across various applications. Featuring a durable vinyl coating over galvanized or annealed steel core wires, our PVC Barbed Wire offers enhanced corrosion resistance, extended service life, and vibrant color options like green, blue, yellow, and gray. It is ideal for military zones, private properties, agricultural lands, and critical infrastructure protection.
Material and Coating
The core of our PVC Barbed Wire is made from galvanized or black annealed steel wire. The outer surface is coated with high-strength polyvinyl chloride (PVC), providing excellent weather resistance and improved abrasion tolerance.
- Core Wire Diameter (before coating): 1.0 mm – 3.5 mm
- Outer Diameter (after coating): 1.4 mm – 4.0 mm
- PVC Coating Thickness: 0.4 mm – 0.6 mm
Common Wire Configurations
Our PVC Barbed Wire is available in multiple twist types and barb styles.
- Single twisted
- Double twisted
- Traditional twist
- PVC or PE coated options
- Barb spacing: 7.5 cm – 15 cm
- Barb length: 1.5 cm – 3.0 cm
Standard Color Options
Available in multiple shades to suit aesthetic or camouflage needs:
- Green (RAL 6005), Blue, Yellow, Orange, Gray
- Custom colors available upon request
Packaging Options
Each coil is wrapped in PVC or hessian cloth, lined with protective strips to prevent damage during handling.
- Standard coil weights: 25 kg, 30 kg, 50 kg
- Standard coil lengths: 50 m, 100 m, 250 m, 400 m
Tensile Strength
- PVC Coated Barbed Wire: 30 – 45 kg/mm²
- Suitable for high-stress environments including marine and irrigation applications
Typical Coil Weights and Shipping Data
| Gauge of Strand and Barb in B.W.G. | Approximate Length per Kilo in Meter | |||
|---|---|---|---|---|
| Barbs Spacing 3″ | Barbs Spacing 4″ | Barbs Spacing 5″ | Barbs Spacing 6″ | |
| 12 × 12 | 6.0617 | 6.7590 | 7.2700 | 7.6376 |
| 12 × 14 | 7.3335 | 7.9051 | 8.3015 | 8.5741 |
| 12-1/2 × 12-1/2 | 6.9223 | 7.7190 | 8.3022 | 8.7221 |
| 12-1/2 × 14 | 8.1096 | 8.814 | 9.2242 | 9.5620 |
| 13 × 13 | 7.9808 | 8.899 | 9.5721 | 10.0553 |
| 13 × 14 | 8.8448 | 9.6899 | 10.2923 | 10.7146 |
| 13-1/2 × 14 | 9.6079 | 10.6134 | 11.4705 | 11.8553 |
| 14 × 14 | 10.4569 | 11.6590 | 12.5423 | 13.1752 |
| 14-1/2 × 14-1/2 | 11.9875 | 13.3671 | 14.3781 | 15.1034 |
| 15 × 15 | 13.8927 | 15.4942 | 16.6666 | 17.5070 |
| 15-1/2 × 15-1/2 | 15.3491 | 17.1144 | 18.4060 | 19.3386 |
Applications
- Perimeter security for residential and commercial properties
- Military compounds and detention facilities
- Highway, railway, and grassland enclosures
- Coastal and high-humidity regions due to enhanced corrosion resistance
